Body Material: ABS
Size: 116*82*18mm (4.57″*3.23″*0.71″)
Filling: Epoxy+Quartz sand
Lens Material: PMMA
Raised Road Pavement Marker Features:
•Reflective studs water, oil, chemical, and heat resistance.
•Raised Road Pavement Marker can work more than 3 years normally.
•Very high reflectivity.
•Raised Road Pavement Marker easy installation with glues.
•Photometric values:exceeds 600(mcd/lux).
Raised Road Pavement Marker Parameters:
| Body material: | ABS |
| Filling: | Epoxy+Quartz Sand |
| Lens Material: | PMMA |
| Reflector type: | Double side/Single side |
| Quality: | ASTM D4280 & EN1463-1 standard |
| Size: | 116*82*18mm (4.57″*3.23″*0.71″) |
| Packing: | 23.5*8.5*19.5cm,100pcs/ctn (9.25″*3.35″*7.67″,100pcs/ctn) |
| Weight: | 110g/pc; 11kg/ctn (0.24bs/pc; 24.25bs/ctn ) |
Installation Method Of Raised Road Pavement Marker:
1. Determine the installation location and distance, clean the road surface, and ensure that the Raised Pavement Markers are installed on a flat road surface.
2. Clean the bottom of the Raised Road Pavement Marker and apply the epoxy glue evenly to the back of the studs.
3. Press the side with the glue on the road, fix the position, wait for the glue to dry.
4. Check within 2 hours of installation to ensure that all Raised Road Pavement Markers are not installed incorrectly and are not bent or deformed due to compression.
5. Remove the installation isolation facility within 6-8 hours after the installation of the Road Pavement Marker.
